Fiber Laser Scan Lub Taub Hau

Fiber Laser Scan Lub Taub Hau

Fiber laser scan lub taub hau, tseem hu ua galvo scanner lossis galvanometer scanner. Nws yog lub luag haujlwm kom raug coj cov kab teeb laser mus rau cov khoom uas tau engraved los ntawm ceev ceev cov iav. Cov tshuab luam ntawv no tau tsim los ua haujlwm tshwj xeeb nrog fiber ntau lasers, uas feem ntau siv rau kev kos thiab kos cov hlau, ceramics, thiab qee cov yas.

Qhov no Fiber Laser Scan Lub Taub Hau muaj kev ruaj ntseg zoo, kev ua haujlwm siab, kev ua haujlwm nrawm nrawm, muaj peev xwm tiv thaiv kev cuam tshuam, thiab tag nrho kev ua haujlwm ntawm lub taub hau scanner tau mus txog qib thoob ntiaj teb hauv daim teb no. Nws nta qis drift, siab positioning raug thiab txhim khu kev qha thiab ruaj khov ua haujlwm nrog kev ua tau zoo tag nrho. Nws tuaj yeem xaiv lo ntsiab muag ntawm qhov sib txawv wavelengths thiab qib zog.

Khoom nta

■ Fiber Laser Scan Lub Taub Hau txais cov photoelectric sensors uas tuaj los ntawm Amelikas, thiab muaj cov cuab yeej cuab tam kev txawj ntse.

■ Sib txawv photoelectric sensor rau qhov tseeb ntawm lub cev muaj zog rotor txoj hauj lwm, zoo linearity, qis drift, siab daws teeb meem thiab rov ua dua.

■ Cov qauv tsim kom raug rau 22 hli tsom iav, qhov tseeb ntawm lub cev muaj zog sib dhos, cov qauv tsim nyog, me me zoo li qub kev sib txhuam coefficient thiab xoom offset, txhua yam ua kom zoo tshaj plaws dynamic yam ntxwv rau tag nrho lub cev.

■ Tsav nrog kev paub txog kev muaj peev xwm ntawm txoj haujlwm thiab kev nrawm, txhim kho cov lus teb zoo heev thiab kev soj ntsuam ceev ntawm tag nrho cov kab ke.

■ Tsim kev tshaj tawm, dhau-tam sim no thiab rov qab txuas kev tiv thaiv, ua rau lub cev ua haujlwm tau zoo dua.

■ Tag nrho cov txheej txheem tau txais kev tsim kho kom zoo ntawm electromagnetic compatibility, nrog rau cov teeb liab-rau-suab nrov piv thiab muaj zog tiv thaiv kev cuam tshuam.

■ Lub tshuab scanner no daws cov teeb meem tshwm sim ntawm lub cev muaj zog drift, teeb liab cuam tshuam thiab xoom drift, thiab lwm yam.

Technical Parameters

Fiber laser scan taub hau muaj xws li cov hauv qab no lub ntsiab Cheebtsam

 Galvanometer lub cev muaj zog:Cov motors no tswj txoj hauj lwm ntawm daim iav los ntawm kev hloov hluav taws xob cov teeb liab mus rau hauv cov tshuab ua haujlwm. High-quality galvanometer motors kom ceev thiab meej txav, ua rau kom nrawm nrawm dua thiab raug zoo dua.



 Daim iav:Cov iav nyob rau hauv lub taub hau scan yog lub luag hauj lwm rau kev xav thiab coj lub laser beam mus rau cov khoom. Cov iav no feem ntau yog ua los ntawm cov khoom siv zoo heev thiab ruaj khov, muaj peev xwm tiv taus cov qib siab zog cuam tshuam nrog fiber ntau lasers.



 Lens:Lub lens nyob rau hauv lub taub hau scan yog lub luag hauj lwm rau tsom lub laser beam mus rau cov khoom ntawm qhov pom qhov chaw loj thiab lub zog ceev. Qhov no tso cai rau kom huv thiab meej cov cim lossis kos rau ntawm cov khoom.



 Tswj electronics:Cov khoom siv hluav taws xob tswj xyuas kev sib txuas lus ntawm galvo scanner thiab lwm yam khoom ntawm lub laser npav system, xws li laser qhov chaw thiab tswj software.



    Thaum xaiv lub taub hau fiber ntau laser scan, nws yog ib qho tseem ceeb uas yuav tau xav txog yam xws li scanning ceev, precision, thiab aperture loj raws li cov kev cai tshwj xeeb ntawm koj qhov project. Ntxiv mus, compatibility nrog koj laser system thiab tswj software kuj tseem ceeb rau seamless lag luam. Thaum kawg, nws yog ib lub tswv yim zoo los xaiv lub npe nrov npe kom ntseeg tau qhov zoo thiab kev ntseeg siab.
