CO₂ Laser Engraving Tshuab
CO₂ Laser Engraving Tshuab
Khoom Description
CO₂ laser engraving tshuab yog cov tshuab txiav tshuab siv nyob rau hauv lub ntiaj teb ntawm laser engraving. Cov tshuab no siv lub tshuab hluav taws xob CO₂ laser uas muaj zog los kos lossis txiav cov ntaub ntawv xws li ntoo, acrylic, tawv, ntawv, thiab lwm yam. Cov cav tov muaj ntau yam zoo kawg thiab tuaj yeem siv los tsim cov qauv sib txawv lossis cov logos yooj yim, nyob ntawm tus neeg siv cov kev xav tau.
Nta thiab qhov zoo
|
Marking ceev yog ceev. Qhov siab tshaj plaws tuaj yeem yog 8000mm / s |
| Yooj yim kawm thiab siv. |
| ruaj khov heev, yuav luag tsis tas yuav hloov cov khoom tom qab ua haujlwm ntev. |
| High precision, engraving qhov tob tswj tau. |
| Beam zoo yog zoo, siab photoelectric conversion efficiency. |
| Lub neej ntev: lub neej expectant yuav yog 20, 000~ 30, 000 teev. |
| All-in-one tsim, txuag chaw thiab yooj yim txav mus los. |
| Tsis xav tau cov khoom siv. |
| Txhawb cov ntaub ntawv sib txawv: PLT, DXF, BMP, JPG, thiab lwm yam. |
|
OEM customization tuaj yeem lees txais. |
Cov ntaub ntawv siv tau
| tawv | ntaub | ntoo | textile |
| reflective/lettering zaj duab xis | xyoob | ntau yam pob zeb | ris / denim |
| ntawv, board | iav | acrylic ntawv | ceramics |
Muaj kev lag luam
| khaub ncaws | ris / denim | acrylic xim | khoom ua si |
| hluav taws xob | kev tshaj tawm | khau, hnab | khoom plig |
| ntim | tshuaj kho mob | zaub mov | tsheb |
Tsis muaj
|
TSIS MUAJ. |
Lub npe |
DS-LMC series Galvo laser system |
|
1 |
Tshuab qauv |
DS-LMC150/DS-LMC250/DS-LMC350 |
|
2 |
Max laser zogr |
150W/250W/350W |
|
3 |
laser wavelength |
10.6μm |
|
4 |
Beamzoo |
＜1.2㎡ |
|
5 |
Lub luag haujlwm lub voj voog txwv |
Tsawg dua lossis sib npaug li 60% |
|
6 |
Min. kabdav |
0.17mm (nyob ntawmntawm cov khoom) |
|
7 |
Qhov loj me me |
0.4 hli |
|
8 |
Maxcimceev |
Tsawg dua los yog sib npaug8, 000mm/s |
|
9 |
Chaw ua haujlwm |
400x400mm / 500x500mm / 600x600mm / 800x800mm |
|
10 |
Txias |
Dejtxias |
|
11 |
Kev ua haujlwm ib puag ncig qhov kub thiab txias |
5 ~ 35 degree |
|
12 |
Cov av noontauntawm qhov chaw ua haujlwm |
< 70% Tsis muaj condensation |
|
13 |
Fais fab mov |
220V, 50/60Hz |
|
14 |
Hwj chimnoj |
＜6 kWm |
CO₂ laser engraving tshuab cov neeg siv khoom sab qhia
Cov qauv qhia
Yuav siv CO₂ laser engraving tshuab li cas?
1: Thaum koj tau txais CO₂ laser engraving tshuab koj yuav tsum nruab cov xov hlau rau lub zog loj, xyuas txhua yam zoo;
2:Ntxiv cov dej Purified rau lub txias chiller, uas yuav muab kev tswj kub zoo meej
3:Xaiv thaj chaw ua haujlwm, pib lub PC thiab ua kom thaj chaw ua haujlwm sib txuam nrog lub galvo dynamic, lub sijhawm koj yuav tsum tau kho cov iav kom tau txais cov ntaub ntawv z axis raug;
4:Ua kom pom tseeb rau thaj chaw ua haujlwm zoo, yog tias ua kom pom tseeb tsis zoo ces lub cim kab yuav loj thiab tsis tuaj yeem ua tau zoo txiav, tshwj xeeb tshaj yog rau lub kaum sab xis;
5:Xaiv cov software thiab import cov ntaub ntawv vector, PLT DXF, teeb tsa txoj cai parameter rau cov khoom siv tam sim no, ceev, lub zog, zaus;
6: Ua qhov chaw thiab ua kom pom liab liab thiab ua koj lub laser engraving lossis txiav;
Shipping thiab pob
1. Kev ruaj ntseg zoo thiab kev pab cuam tom qab muag
Lub sijhawm lav ntawm cov cuab yeej yuav tsum yog 12 lub hlis txij li cov khoom siv los ntawm cov neeg siv khoom, kev teeb tsa thiab kev debugging tiav thiab cov khoom siv tau txais los ntawm tus neeg thov. Dotslaser muab qhov tseem ceeb rau kev ua haujlwm tom qab muag ntawm cov khoom, thaum cov khoom xa tuaj rau tus neeg siv, lub tuam txhab tam sim ntawd tsim cov ntaub ntawv cov neeg siv khoom tom qab muag, thiab tsis tu ncua taug qab tus neeg siv khoom siv cov xwm txheej, daws thiab teb tag nrho cov teeb meem ntawm tus neeg siv, tau txais cov neeg siv cov ntaub ntawv ceeb toom txog cov khoom siv tsis ua haujlwm, lub tuam txhab cov neeg ua haujlwm tuaj yeem ua cov lus teb sai hauv 2 teev. Yog tias kev taw qhia hauv xov tooj yog qhov nyuaj rau kev daws teeb meem, peb lub tuam txhab cov neeg ua haujlwm txawj tuaj yeem tuaj txog ntawm qhov chaw neeg siv khoom hauv 24 teev los muab kev txhawb nqa.
2. Kev teeb tsa thiab kev debugging
Ua ntej kev teeb tsa lub tshuab, peb lub Hoobkas yuav muab cov ntaub ntawv tsim nyog rau koj, qhov xav tau zoo 2 lub lis piam xa tuaj rau koj nyob ntawd, cov engineers ntawm Dotslaser yuav tuaj txog ntawm koj qhov chaw thiab tshuaj xyuas lub tshuab dua. Xyuas kom meej tag nrho cov xwm txheej ua tau raws li qhov yuav tsum tau ua ntawm installation thiab commissioning, cov cuab yeej yuav thauj mus rau lub sijhawm. Lub sijhawm teeb tsa thiab kev ua haujlwm ntawm cov cuab yeej siv yog li tsib hnub ua haujlwm, thawj peb hnub tau txuas nrog kev siv lub tshuab, thiab lub kaw lus ua haujlwm tom qab qhov kev pabcuam. Tus kws ua haujlwm yuav cob qhia cov neeg ua haujlwm tsim nyog ntawm cov txheej txheem kev saib xyuas yooj yim thiab cov yam ntxwv ntawm cov khoom siv hauv ob hnub tom ntej
3. Kev pab txhawb nqa
Yog tias muaj teeb meem nrog ib feem ntawm lub cev thaum lub sijhawm lav, Dotslaser cov kws tshaj lij kev pabcuam zoo yuav muab xov tooj hu lossis pib qhov kev pabcuam ntawm qhov chaw, yog tias lub tshuab muaj teeb meem thaum lub sijhawm lav, thov hu rau peb ncaj qha!
