Zoo Vuam Tshuab
Zoo Vuam Tshuab
Khoom Description
Lub tshuab vuam zoo tuaj yeem nqa tawm mus ntev, loj workpiece laser welding, thiab vuam qhov kub ntawm qhov cuam tshuam me me, uas yuav tsis ua rau workpiece deformation, blackening, rov qab qhov teeb meem, thiab vuam qhov tob, khoom vuam, tawg. yog txaus, dissolution pas dej dissolution khoom tsa ib feem ntawm kev sib txuas nrog lub substrate yam tsis muaj kev nyuaj siab tshwm sim.
Khoom nta
| 1. Lub laser beam zoo yog zoo, vuam ceev ceev, vuam seam yog ruaj khov thiab zoo nkauj, thiab nws coj cov neeg siv ib tug npaum thiab zoo meej vuam tov. |
| 2. Hand-held water-cooled welding gun, ergonomic design, saj zawg zog thiab yooj yim, ntev vuam nrug, thiab tuaj yeem welding workpiece ntawm txhua lub kaum ntse ntse. |
| 3. Qhov chaw vuam tsis muaj cua sov me ntsis, tsis yooj yim rau deformed, blackened, thiab muaj kab nyob rau tom qab. Lub vuam qhov tob yog loj, lub melting yog txaus, thiab nws yog ruaj thiab txhim khu kev qha. |
| 4. Kev hloov pauv hluav taws xob ntau dua, kev siv hluav taws xob qis dua, thiab kev ua haujlwm yooj yim thiab yooj yim kawm. Tsis tas yuav tsum muaj tus kws tshaj lij vuam tshuab. Cov neeg ua haujlwm ib txwm tuaj yeem pib tom qab kev cob qhia luv luv. Kev siv mus sij hawm ntev tuaj yeem txuag tau cov nqi ua haujlwm. |
| 5. Kev nyab xeeb siab, qhov vuam taub tsuas yog siv tau thaum lub tshuab hloov pauv thaum nws kov cov hlau, thiab qhov kov hloov pauv muaj lub cev kub sensor. |
| 6. Nws tuaj yeem paub qhov vuam ntawm txhua lub kaum ntse ntse, thiab tuaj yeem vuam ntau yam welded workpieces thiab loj workpieces nrog cov duab tsis zoo. Paub welding ntawm txhua lub kaum ntse ntse. |
Main Parameters Thiab Configurations
| Qauv | DS-LW 1000/DS-LW 1500/DS-LW 2000/DS-LW 3000 |
| Laser zog | 1000W/1500W/2000W/3000W |
| Lub wavelength | 10 80nm |
| Vuam nkag | 0.5 ~ 5 hli |
| Qhov loj me | 0.2 ~ 1.8 hli |
| Vuam khoom | carbon steel, stainless hlau, galvanized ntawv, txhuas, tooj liab, tooj dag, txhuas alloy, hlau .. |
| Laser qhov chaw | MAX/Raycus/JPT/IPG |
| Optical fiber ntau cable | 10 meters |
| Total powe | 5 kWm |
| Fais fab mov | 220V / 380V, 50/60HZ |
Rhiav ntawm Dotslaser
Kev tu txhua hnub
● Tom qab ua haujlwm tiav, xyuas kom cov hauv pem teb huv si. Tom qab ntawd ntxuav lub tshuab nrog rau saum npoo ntawm lub tshuab, rooj plaub ntawm qhov kho qhov muag, qhov chaw ntawm lub monitor, lub rooj ua haujlwm, thiab lwm yam.
● Thov tua txhua ntu thiab lub zog loj thaum lawv huv si.
● Tshawb xyuas lub lens tsis tu ncua rau cov plua plav. Thaum nws huv si, siv cov paj rwb wool nrog ntau dua 95% cawv qib kho mob los so clockwise los ntawm qhov chaw ntawm lub lens. Thaum koj xav tau txav lub tshuab kom tsis txhob muaj pob. Txheeb xyuas qhov kev sib txuas ntawm cable raws li daim ntawv teev npe cable.
