Laser Welding rau High Conductivity Copper
Laser Vuam RauHigh Conductivity tooj liab
Khoom Description
Laser Vuam Rau High Conductivity Copper Busba yog txheej txheem nyuaj uas yuav tsum muaj kev tswj xyuas meej ntawm laser tsis, suav nrog lub zog laser, beam txoj kab uas hla, mem tes ntev, thiab rov ua dua tus nqi. Cov kev txwv no cuam tshuam rau lub zog ceev ntawm lub laser beam, uas nyob rau hauv lem cuam tshuam cov weld zoo thiab cov khoom. Ib qho ntawm cov teeb meem tseem ceeb yog kom ua tiav lub zog txaus kom kov yeej cov thermal conductivity siab ntawm cov khoom siv tooj liab thaum tsis txhob muaj cua sov ntau dhau uas tuaj yeem ua rau thermal puas thiab vuam tsis xws luag, xws li porosity thiab cracking.
Tshuab Zoo
| 1.Qhov X, Y, Z, thiab D axis ntawm lub workpiece yuav tsum tau welded yog kauj ruam-tsav kom tau raws li cov kev xav tau ntawm kev mus los loj. | |||
| 2.CCD duab saib xyuas kom muaj kev ruaj ntseg ntawm vuam zoo. | |||
| 3.Lub taub hau laser tsis nyob rau hauv kev sib cuag nrog lub workpiece, thiab tsis muaj teeb meem ntawm hnav ntawm cov cuab yeej ua. | |||
| 4.Lub workpiece tsis ntxhov siab thiab tsis yooj yim kom muaj kuab paug; | |||
| 5.Nws tuaj yeem ua cov haujlwm txav mus los lossis cov khoom ntim hauv lub khob iav; | |||
| 6.Multi-axis nrog nws pib ua kom pom tseeb thiab kev sib hloov ua haujlwm, nws yog qhov ntse rau vuam cov khoom ntawm txhua yam duab hauv 3D qhov chaw. | |||
| 7. CNC tsis siv neeg tswj kom paub tseeb tias vuam cheeb tsam uniformly. | |||
| 8. Vuam seam du thiab zoo nkauj, tsis xav tau polishing, txuag koj lub sijhawm. |
- Tsis muaj
|
Qauv |
DS-LW 3000 |
DS-LW 4000 |
DS-LW 6000 |
DS-LW 12000 |
|
Laser fais fab tso zis |
3000W |
4000W |
6000W |
12000W |
|
Laser wavelength |
1070 ± 5nm |
|||
|
Laser hom |
Fiber ntau |
|||
|
Kos thaj tsam |
800mmx300mmx300mm |
|||
|
Pulse zaus |
1 ~ 100KHZ |
|||
|
Beam zoo |
1.1 hli |
|||
|
Kho lub zog ntau yam |
5-95% |
|||
|
Cov zis fiber ntau ntev |
5/10/15m (yeem) |
|||
|
Qhov hnyav |
500 KG |
|||
|
Txias |
Dej txias |
|||
|
Ua haujlwm temp |
10 ~ 35 degree |
|||
|
Humidity ntau |
< 70% No condensation |
|||
|
Fais fab mov |
AC220V ± 10%, 50Hz lossis AC380V ± 10%, 60Hz |
|||
Laser vuam ntawm high conductivity tooj liab yog ib tug complex txheej txheem uas yuav tsum tau meej tswj ntawm laser tsis, xws li laser hwj chim, beam txoj kab uas hla, mem tes ntev, thiab repetition tus nqi. Cov kev txwv no cuam tshuam rau lub zog ceev ntawm lub laser beam, uas nyob rau hauv lem cuam tshuam cov weld zoo thiab cov khoom. Ib qho ntawm cov teeb meem tseem ceeb yog kom ua tiav lub zog txaus kom kov yeej cov thermal conductivity siab ntawm cov khoom siv tooj liab thaum tsis txhob muaj cua sov ntau dhau uas tuaj yeem ua rau thermal puas thiab vuam tsis xws luag, xws li porosity thiab cracking.
Laser vuam tshuab ua haujlwm li cas?
Nyob rau hauv cov txheej txheem laser vuam, lub teeb pom kev zoo ntawm lub teeb yog tsom rau ntawm kab noj hniav ntawm cov ntaub ntawv yuav tsum tau koom nrog. Lub zog laser beam melts cov ntaub ntawv ntawm lawv cov seams thiab fuses rau hauv ib qho kev sib koom ua ke. Nrog xws li ib tug heev concentrated tshav kub qhov chaw siv, laser welding nyob rau hauv nyias cov ntaub ntawv yuav ua tau nyob rau hauv high speeds. Hauv cov ntaub ntawv tuab, laser vuam tuaj yeem tsim cov welds sib sib zog nqus thiab nqaim.
Dab tsi yog hom kev sib txawv ntawm Laser Vuam?
Ntiv nplhaib hom Laser Vuam
Lub nplhaib hom Laser Vuam yog siv lub zog ntawm lasers los tsim cov welds muaj zog thiab meej. Lub tshuab tshiab no yog nrawm dua, ua haujlwm tau zoo, thiab txhim khu kev qha ntau dua li cov txheej txheem vuam tsoos. Nrog lub nplhaib hom Laser Vuam, lub teeb tsom teeb laser yog siv los tsim lub qhov tseem ceeb hauv cov khoom siv welded, uas yog tom qab ntawd ntim cov hlau molten los ua kom muaj zog, seamless bond. Qhov no yog cov cuab yeej muaj txiaj ntsig uas tuaj yeem siv rau ntau yam khoom siv, suav nrog hlau thiab yas.
Ib hom Laser nrog Wobble Vuam
Tib hom Laser nrog Wobble Vuam yog ib qho kev siv thev naus laus zis uas ua kom yooj yim thiab siv tau zoo. Cov txheej txheem tshiab no tuaj yeem tsim cov welds zoo nrog qhov sib txawv me me thiab cov khoom siv hluav taws xob tsawg. Lub tshuab ua haujlwm los ntawm kev siv lub tshuab hluav taws xob laser siab uas tau tsom mus rau ib hom, uas tso cai rau nws tsim qhov chaw me me heev.
Ntsuab Laser Vuam
Green Laser Welding yog ib qho kev siv tshuab tshiab uas tau hloov pauv kev lag luam vuam. Nws siv lub teeb ntsuab laser los koom nrog ob lossis ntau daim hlau nrog kev ua haujlwm siab thiab raug. Piv rau cov txheej txheem vuam tsoos, nws yog qhov ua tau zoo dua, nrawm dua, thiab tus phooj ywg zoo ib puag ncig. Ib qho txiaj ntsig tseem ceeb ntawm ntsuab laser vuam yog nws lub peev xwm los vuam nyias, muag heev, thiab cov hlau tsis yooj yim uas yuav tsis yooj yim rau vuam nrog cov txheej txheem. Nws precision thiab raug tau lees paub qhov zoo, huv-zoo li vuam.
Nanosecond laser vuam
Nanosecond laser welding yog ib qho kev siv thev naus laus zis uas ua rau cov txheej txheem vuam zoo, ua tau zoo thiab zoo. Cov txheej txheem no siv lub laser pulsing beam uas kav ntev li ob peb nanoseconds, ua kom muaj cua sov qhov chaw uas melts cov khoom raug welded. Lub tshav kub cuam tshuam yog qhov tsawg, yuav luag tsis muaj thermal distortion thiab weld shrinkage.
Laser tiv thaiv tsom iav yog tsom iav tshwj xeeb uas tuaj yeem tiv thaiv lossis txo cov laser puas rau tib neeg lub qhov muag.
Thaum xaiv cov tsom iav tiv thaiv, raws li qhov siab tshaj plaws tso zis hluav taws xob (los yog lub zog) ntawm lub laser siv, optical ceev (qhov loj dua OD: OD tus nqi, qhov muaj zog tiv thaiv lub peev xwm ntawm laser tiv thaiv tsom iav), pom lub teeb transmittance (pom pom lub teeb transmittance. : tus nqi qis dua 20%, laser tsom iav kev nyab xeeb yuav tsum tau siv nyob rau hauv qhov chaw muaj teeb pom kev zoo) xaiv.
